GM25-2 Portable Gas Analyser
GM25-2 Portable Gas Analyser
Reference:
3100000000243
The GM25-2 is an ATEX certified gas analyzer, designed for diverse applications. It is fully configurable according to each customer's needs, making it an exceptionally versatile instrument.
It can be configured with infrared channels for the analysis of CH₄ and CO₂ , with optional LEL expansion and up to four electrochemical cells to measure any combination of O₂ , CO, H₂S or H₂ . With the N₂ balance calculation option, customers can choose up to 7 gas channels.
This instrument is capable of providing three different optional pressure measurements: atmospheric, static (manometric), and differential.
Optional extras are available to measure speed and temperature.
Do you have any doubts? Contact us and we'll help you.
Ask for informationThe GM25-2 is an ATEX certified gas analyzer, designed for diverse applications. It is fully configurable according to each customer's needs, making it an exceptionally versatile instrument.
It can be configured with infrared channels for the analysis of CH₄ and CO₂ , with optional LEL expansion and up to four electrochemical cells to measure any combination of O₂ , CO, H₂S or H₂ . With the N₂ balance calculation option, customers can choose up to 7 gas channels.
This instrument is capable of providing three different optional pressure measurements: atmospheric, static (manometric), and differential.
Optional extras are available to measure speed and temperature.
- Ex Rating: EEx ib IIB T1
- Gas analyzer with custom selection
- Provides measurements of up to 6 gases (CH4, CO2, O2, H2S, H2, CO)
- Optional expansions to measure atmospheric, static, and differential pressures.
- Simple reports: via Instrument Connect software or the DataField GM25 Connect app
- Small and portable design: easily fits in one hand.
- 12-month service interval
- High-contrast LCD screen
- User-replaceable battery pack
- Battery life ranges from 8 to 12 hours and charging time is 4 hours.
- Charger suitable for the client's country
- Weather-resistant neoprene protective case
- Optional vane anemometer for measuring gas speed from 0.5 to 40 m/s
- Optional additional brass probe for measuring gas temperature.
All GM25 instruments require annual servicing and recalibration.
Thanks to the configurable design of the GM25-2, it is suitable for almost any gas analysis application, including:
- Biogas monitoring
- Wastewater and sewage treatment
- Odor monitoring
The GM25-2 Gas Analyzer operates using specific sensors that detect the presence and concentration of gases in the environment. The device samples the air and displays the obtained values quickly and clearly, allowing the user to evaluate the situation in real time.
Its portable and rugged design allows for extended use in the field or industrial facilities, ensuring reliable and consistent data for decision-making related to safety, environmental control, and process management.
Versatile Multigas Analyzer
Allows configuring the instrument according to your specific measurement needs, with the ability to measure up to six gases simultaneously in different ranges.
Certification and Safety
With ATEX, IECEx, and UKEx certifications, the GM25-2 can be safely used in environments with the risk of explosive atmospheres, making it suitable for demanding industrial and environmental sites.
Intelligent Data Management
Integration with DataField GM25 Connect allows controlling the analyzer from mobile devices, transmitting data in real time, and simplifying the management of sampling campaigns.
Portable and Durable
Its compact design, lightweight, and long battery life make it an ideal tool for continuous fieldwork without losing accuracy.
Measurement Flexibility
Additional options like pressure, temperature, and gas velocity measurement expand the equipment's capabilities, providing more comprehensive information during inspections.
