Kimo LV111 Anemometer: portable thermo-anemometer with 14 mm vane probe for measuring velocity, airflow, and temperature, ideal for HVAC, ventilation, and facility control
Do you have any doubts? Contact us and we'll help you.
Ask for informationThe Kimo LV111 anemometer is a specialized portable instrument for accurately and reliably measuring air velocity, flow rate, and ambient temperature in HVAC applications, ventilation, and air system control. This vane thermo-anemometer with a Ø 14 mm probe has been designed to provide detailed readings even in narrow ducts or hard-to-reach areas, facilitating diagnostic and optimization tasks of air conditioning systems, industrial facility maintenance, and environmental monitoring.
Equipped with advanced functions such as flow rate calculation, automatic averaging, value hold (HOLD), and maximum and minimum values, this instrument allows the user to precisely analyze variations in airflow and temperature, presenting information on a multi-line LCD screen with multiple units of measurement
- Measured parameters: air velocity, flow rate, and temperature.
- Velocity range: from 0.80 m/s to 25 m/s.
- Flow rate range: up to 99 999 m³/h (depending on configuration and accessories).
- Temperature range: –20 °C to +80 °C (depending on probe).
- Additional functions: flow calculation, automatic averaging, HOLD function, and recording of minimum and maximum values.
- Display: LCD (multiple lines with unit reading).
- Protection: ABS housing with IP54 (dust and splash resistance).
- Power supply: 4 AAA LR03 1.5 V batteries.
- Weight: approx. 390 g.
The duct surface is entered into the portable anemometer and it will display the average flow based on the time or point average. For flow calculation, simply enter the duct diameter into the portable anemometer, and based on the time or point average, it will display the average flow. By clicking on the hold function, the current measurement value is retained on the screen or you can access the minimum and maximum values.
- Precise and versatile measurements: Thanks to its small-diameter vane probe and specific sensors, the LV111 provides reliable measurements of air velocity and temperature, even in ducts and confined spaces.
- Practical field functions: Includes automatic flow rate calculation, averaging, min/max values, and HOLD function, facilitating trend analysis and real-time flow conditions.
- Adaptable units: Allows selection between multiple measurement units (m/s, km/h, fpm, m³/h, cfm, etc.), making it versatile for different application standards.
- Robust and portable design: Its durable casing with IP54 protection and compact size allow for comfortable use in the field for extended periods.
